Philips Semiconductors
UM_1SPP
BGB203 BT 2.0 Serial Port Profile Module User’s Guide
Table 7: Profil e Filter
Value
0x00000001
0x00000002
0x00000004
0x00000008
0x00000010
0x00000020
0x00000040
0x00000080
0x00000100
0x00000200
0x00000400
0x00000800
0x00001000
0x00002000
Profile
Serial Port profile
Headset profile
Dial-up Networking profile
Fax profile
LAN Access profile
OBEX Object Push profile
OBEX File Transfer profile
OBEX Object Synchronization profile
Hands Free profile
SIM Access profile
Basic Printing profile
Basic Imaging profile
Video Distribution profile
Phonebook Access profile
The command will accept hexadecimal input (as listed above) by
pre-appending “ \x ” or “ \X ” (without the quotation marks) to the
value. If this prefix is not present, then the value is assumed to
be an integer value (base 10).
Results:
Result will be one (or more lines) of one of the following formats:
+BTSDP: <Service Type>, <Profile Version>, “<Service Name>”,
<Port>
where,
<Service Type> represents the type of service. It will be one of
the following values listed in the table below (note that these
values do not match the profile filter values).
? Koninklijke Philips Electronics N.V. 2005
All rights are reserved. Reproduction in whole or in part is prohibited without the prior
written consent of the copyright owner. The information presented in this document does
not form part of any quotation or contract, is believed to be accurate and reliable and may
be changed without notice. No liability will be accepted by the publisher for any
consequence of its use. Publication thereof does not convey nor imply any license under
patent- or other industrial or intellectual property rights.
Date of release:21 Dec 2005
Published in The Netherlands
